NICD Building Newcastle University
Naturalspan Mono-pitch
Project Description

Project: NICD Building Newcastle University

Location: Newcastle-upon-Tyne, England

Main contractor: Bowmer & Kirkland

Specification1No 12,000mm x 10,000mm overall size NLS Tear shaped Mono-pitch NaturalSpan glass rooflight, aluminium glazing bar gasketed system with secondary water management including aluminium flashings to suit. The unit comprised of all bays fixed. All polyester powder coated paint finished to BS 6496 colour tint, Black. Fixing to steel support structure supplied by others.

Glazing Specification

8mm SKN 165 Solar Controlled Toughened Outer, 16mm Argon Filled Cavity, 9.5mm Clear Toughened Laminated Inner
